PARTS CATALOG

HK0003264

D-28596-11

HUBS, WHEEL HUB, TRAILER, AIR DISC BRAKE, PARALLEL SPINDLE, 10 STUD X 11.25" BC, CAN SUBSTITUTE FOR D-31180-1. D-28596-12,10082449, 10082500 BENDIX ADB22X-LT APPLICATION TYPE:- BOTH STEEL AND ALUMINUM WHEELS HUB MATERIAL :- DUCTILE IRON HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 6.75 IN INNER BREAING HM518445 INNER RACE HM518410 INNER SET SET415 OE REF NUMBER S-28534-1 OUTER BEARING HM518445 OUTER RACE HM518410 OUTER SET SET415 OVERALL HEIGHT 8.89 IN WHEEL MOUNT (10) ON 11.25 IN WHEEL OFFSET 1.79 IN WHEEL SEAL WS880065 WHEEL STUD 13-1572

HK0003538

VS-29859

MOUNTING BRACKET, FOR TIRE PRESSURE CONTROL SYSTEM, TIREMAAX CONTROLLER

HK0003262

S-39888-1

HUBS, WHEEL HUB, TRAILER ,AIR DISC BRAKE , PARALLET SPINDLE, 10 STUD X 11.25" BC, BENDIX ADB22X-LT, WABCO PAN22 AIR DISC BRAKE APPLICATION TYPE:- BOTH STEEL AND ALUMINUM WHEELS HUB MATERIAL :_ ALUMINUM IT CAN BE SUBSTITUTE FOR S-39888-2 OR 10082491

HK0003890

S-21165-2

FRAME BRACKET ASSEMBLY, LH, CURBSIDE TOP TO ALIGN HOLE: 10" HT-DOLLY, HC, HT; AND TA, QUICK-ALIGN, FOR ROADSIDE USE S-21165-1

HK0003871

S-32195-2R

WELD-ON FRAME BRACKET, CURBSIDE, FOR VANTRAAX HKAT 50K/69K25/75K25, RIDE HEIGHT 15", 16" , 17"

HK0003771

S-22487-13

RIDE HEIGHT LOCK ASSEMBLY, FOR INTRAAX AAR 23K/25K SUSPENSIONS, SLKF, SLKV AND SLKT, 16" RIDE HEIGHT,

HK0003948

S-22634-1

WINGLESS WELD-ON FRAME BRACKET, QUIK-ALIGN, ROADSIDE, FOR HT HT250U

HK0000829

S-28757

ABS BRACKET

HK0003457

AKH-244B

HEIGHT CONTROL VALVE KIT, DRUM BRAKE, FOR INTRAAX AAT

HK0003251

S-34576-1

HUBS, DrWHEEL HUB, TRAILER, TAPPER SPINDLE, AIR DISC BRAKE , 10 STUD, WABCO PAN22, HALDEX DB22LT APPLICATION TYPE :-STEEL WHEELS ( SHORT STUD) ABS NO BETWEEN THE RACES 3.34 IN DRUM/ROTOR BOLT CIRCLE (10) ON 9.82 IN UM/ROTOR PILOT 8.66 IN HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 5.50 IN INNER BREAING HM218248 INNER RACE HM218210 INNER SET SET414 OUTER BEARING HM212049 OUTER RACE HM212011 OUTER SET SET413 OVERALL HEIGHT 7.22 IN WHEEL SEAL WS880025 WHEEL STUD 13-1571

HK0003680

VS-28865

STEEL AXLE HOSE FITTING, HN, 1.75IN

HK0003769

S-36137

SURELOK SHAFT BRACKET

HK0003363

S-35943-1

HUB CAP, TRAILER, HXL3 HP OIL SIDE FILL BOLT CIRCLE :- 6.75 IN .HOLES :- 6

HK0003263

D-31180-1

HUBS, WHEEL HUB, TRAILER, AIR DISC BRAKE,PARALLEL SPINDLE 10 STUD X 11.25" BC, MATERIAL :- ALUMINUM SPLINED APPLICATION TYPE :- BOTH STEEL AND ALUMINUM WHEELS CAN BE SUBSTITUTE FOR D-31180-2 , 10082499, 10082450 BEARING SET (INBOARD) SET: 415 OR 432 BEARING SET (OUTBOARD) SET: 415 OR 432 ROTOR TYPE FLAT REPLACEMENT ROTOR KIT 10085621 WHEEL STUD STANDOUT (IN.) 3.44 FLANGE OFFSET (IN.) 1.79 ABS TONE RING INCLUDED YES WEIGHT (LBS.) 130 PRESET / PRESET PLUS HUB REBUILD KIT :-10081731

HK0002835

VS-32331

TIREMAAX PRO CONTROLLER TEST GAUGE

HK0003620

VS-33686

PORT PROTECTION PLUG, HUB CAP, FITS TIREMAAX PRO/CP INTEGRATED HUB CAPS 3/4IN-20 UNEF

HK0000705

S-24705

HENDRICKSON PIVOT BOLT KIT

HK0003838

S-29184-1R

FRAME BRACKET RH HENDRICKSON, CURBSIDE, FOR ROADSIDE USE S-26874-2R INTRAAX AANLS 20K, 9" ROAD HEIGHT WELD-ON

HK0003240

10082497

HUBS, WHEEL HUB, TRAILER , DISC BRAKE TYPE,TAPPER SPINDLE 10 STUD, PRESET, ABS, BENDIX ADB22X-LT, APPLICATION TYPE :- STEEL WHEELS BEARING NUMBER INBOARD - 246 431 BEARING NUMBER OUTBOARD - 245 427 FLANGE OFFSET 0.79 IN HUB MOUNTING SYSTEM HP10 HUB RATING 11500 PG LEAD TIME 5 DAYS MATERIAL ALUMINUM WEIGHT 118.0 PG WHEEL STUD BOLT CIRCLE DIAMETER 11.25 IN WHEEL STUD STANDOUT 2.56 IN WHEEL STUD THREAD M22 X 1.5 MM MM

HK0003687

S-28193

ROTARY UNION KIT, TIREMAAX ROTARY UNION SPINDLE PLUG RETROFIT KIT 2-3/4" HP HUS P90

HK0003788

S-26104-1R

FRAME BRACKET ASSEMBLY, 12" RIDE HEIGHT, HENDRICKSON

HK0003650

VS-32101

TIREMAXX AXLE VENT, FOR INTRAAX/VANTRAAX

HK0003673

VS-27449

SPINDLE PLUG END PLUG ASSY, TIREMAAX 2.75" , (FREEZE PLUG)

HK0003776

S-28658-3

OUTER PIN CAGE REPLACEMENT, HENDRICKSON
