PARTS CATALOG

HK0003288

10016195

ROTOR, AIR DISC, FLAT,AIR DISC ROTOR 16.900IN BRAKE TYPE WABCO PAN22 ROTOR TYPE FLAT AOVERALL LENGTH 2.09 INCH BBRAKE SURFACE OUTSIDE DIAMETER Ø16.93 INCH CTHICKNESS 1.77 INCH DPILOT DIAMETER Ø 6.55 INCH E BOLT CIRCLE Ø7.86 INCH NUMBER OF BOLT HOLES 10

HK0003281

S-38764

ROTOR, AIR DISC BRAKE, WABCO PAN22, U-SHAPED ROTOR,430X45, 10 BOLTS, CENTER HOLE DIAMETER 220.0 MM

HK0003130

373-0243

WHEEL SEAL, WHEEL SEAL/ HUB SEAL - 4.625" SPINDLE OD, 6" BORE DIA., 0.981" WIDTH HUB CAP WITH GASKET 340-4009 INNER BEARING CONE HM218248 INNER BEARING CUP HM218210

HK0003107

S-33332/2

SPINDLE NUT/AXLE NUT KIT HENDRICKSON PRECISION 240 HN SPINDLE (INCLUDES (1) SPINDLE NUT, WASHER AND (2) SCREWS))

HK0002580

924-5822

AIR TANK, VOLVO VN, VHD, WET TANK, METRIC PORTS APPLICATIONS VOLVO TRAILER / TRUCK TRUCK DIAMETER (IN) 10.000" MAKE VOLVO CHAMBERS DUAL LENGTH 29.500" TANK MATERIAL STEEL BRACKETS TOP SIDE PORTS (1) M22X1.5 END PORTS (A) (1) M16X1.5, (1) 1/4" NPT TANK END PORTS (B) (3) M22X1.5, (2) M16X1.5, (1) 1/4" NPT

HK0002974

S-31110-16L

S-CAM / CAMSHAFTS CAMSHAFT LH, - 12.25 HENDRICKSON HXS

HK0003098

S-28570-4350

DUST SHIELD,HENDRICKSON, WABCO PAN22, BENDIX ADB22X-LT, HALDEX DB22LT PAN22 DISC BRAKE WITH 5.0IN DIA. AXLE

HK0004583

04-871121

S-CAM/CAMSHAFTS, HENDRICKSON INTRAAX WITH 16-1/2IN HXS, 1.125IN HEAD, 1.5IN-28 SPLINES, (MOST COMMON)

HK0003084

S-22889-1

ABS SENSOR, WHEEL SPEED SENSOR - 19.7 INCH, STRAIGHT

HK0002968

S-31110-34L

CAMSHAFT LH, 12.25 HENDRICKSON HXS

HK0004582

04-871122

S-CAM/CAMSHAFTS, CAMSHAFT LH, INTRAAX WITH 16-1/2IN HXS, 1.125IN HEAD, 1.5IN-28 SPLINES MOST COMMON

HK0003106

S-32844/2

SPINDLE NUT/AXLE NUT KIT HENDRICKSON PRECISION 320

HK0002961

S-30594-8R

CAMSHAFT RH,HEAD THICKNESS 1.13 IN,SPLINE QUANTIT 28, UNDER S-HEAD TO SNAP RING LENGTH 17.38 IN

HK0003074

S-36838-9

CALIPER & THEIR REPAIR KITS AIR DISC BRAKE CALIPER PRESSURE PLATE AIR DISC - PRESSURE PLATE KIT WEB PAN19

HK0004395

12-27200E

AIR HOSE ZINC POGO STICK - 40 IN

HK0003101

S-36224-4430

DUST SHIELD,SERVICE KIT 430, WABCO PAN22, BENDIXADB22X-LT

HK0003532

11-2003

BIN BOX, 3"X12"X4"

HK0003259

D-28596-32

HUBS, WHEEL HUB, TRAILER, AIR DISC BRAKE, 10 STUD X 11.25" BC, TAPPER SPINDLE BENDIX ADB22X-LT AIR DISC BRAKE APPLICATION TYPE :- BOTH STEEL AND ALUMINUM WHEELS MATERIAL :- DUCTILE IRON CAN BE USED AS A SUBSTITUTE OF D-28596-31 ABS YES ABS TEETH 100 BETWEEN THE RACES 3.34 IN DRUM/ROTOR BOLT CIRCLE (10) ON 9.82 IN DRUM/ROTOR PILOT 8.66 IN HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 5.50 IN INNER BREAING HM218248 INNER RACE HM218210 INNER SET SET414 OE REF NUMBER C-34582-2 OUTER BEARING HM212049 OUTER RACE HM212011 OUTER SET SET413 OVERALL HEIGHT 7.82 IN WHEEL SEAL WS880025 WHEEL STUD 13-1572

HK0003953

S-21927-1

FRAME BRACKET ASSEMBLY, WELDON ,WINGLESS, ROAD SIDE, HT250U, HENDRICKSON

HK0003053

6402259262

CALIPER & THEIR REPAIR KITS CALIPER PUSH PLATE KIT RH,MAXX22T, PAN22-1, AIR DISC BRAKE CALIPER PUSH PLATE - PASSENGER SIDE (RH)

HK0003594

441-850005416

SHOCK ABSORBER, COLLAPSED LENGTH :-11.5, LENGTHS STROKE :-5.78, EXTENDED LENGTH:- 17.28,

HK0002975

S-31110-16R

CAMSHAFT RH - 12.25 HENDRICKSON HXS

HK0003055

S-33649-5

CALIPER & THEIR REPAIR KITS DISC BRAKE CALIPER BOLT KIT AIR DISC - AXIAL MOUNT BOLT KIT MAXX22T

HK0003072

12-999-699VT

CALIPER & THEIR REPAIR KITS DISC BRAKE CALIPER PIN KIT AIR DISC - GUIDE PIN KIT PAN17
