PARTS CATALOG

HK0003654

KLE-1005

PG193 - CRIMPING AND CUTTING TOOL FOR CONNECTORS, 10 to 22 AWG INSULATED AND NON INSULATED TERMINALS,

HK0003768

GDP61318701X100.00

DOOR RETAINER FURRING, DOOR UPPER WHITE PVC 100" JAMB GREAT DANE DOOR PVC TOP 100

HK0000492

W16100-R

100 FT PRIMARY WIRE RED 16 GAUGE

HK0000862

CTB1150-100

11.5'' BLACK CABLE TIES 50LBS - 100 PACK

HK0004444

AB1D28C-A965

AIR SPRING,, AIR SPRING ROLLING LOBE , ALUMINIUM BASE DESCRIPTION: • ROLLING LOBE AIR SPRING • ALUMINUM BASE CONSTRUCTION • LOAD CAPACITY: 8,800 LB AT 100 PSI • LOAD CAPACITY: 6,900 LB AT 80 PSI • COMPRESSED LENGTH: 8.5 IN. • EXTENDED LENGTH: 26.5 IN. • OUTSIDE DIAMETER: 13.7 IN.

HK0000494

W214100-G

100 FT GREY JACKETED TRAILER CABLE 2-WIRE 14GAUGE

HK0000491

W16100-W

100 FT PRIMARY WIRE WHITE 16 GAUGE

HK0000534

L12-100

100 FT BLACK SPLIT L;OOM 1/2" I.D

HK0000861

CTB0850-100

8'' BLACK CABLE TIES 50LBS - 100 PACK

HK0001082

1485-6-100

AIR LINE 3/8 DOT AIRBRAKE TUBE 3/8 BLK. 100 FT

HK0004146

FD578100VSM

5 X 7/8, ALUM. OXIDE(BROWN), GRIT 100

HK0002921

AB1DK23I-8803

AIR BAG-AIR SPRING ROLLING LOBE • 5-5/8 INCH PISTON HGT. • PLASTIC BASE APPLICATIONS RIDEWELL SAF HOLLAND/NEWAY TYPE ROLLING LOBE AIRSPRING BRAND AUTOMANN PHOENIX AUTOMANN BELLOWS # 1DK23I FIRESTONE BELLOWS# 1T15M-4 CONTITECH BELLOWS# 9 10-13.5 LOAD (LBS) @80 PSI 5600 LOAD (LBS) @100 PSI 7100 NATURAL FREQ. (CPM) 74 DESIGN HEIGHT (IN) 11.50 BOTTOM PLATE TYPE PLASTIC TOP PLATE HOLE/STUD QTY 2 TOP PLATE DIA. (A) 9.00 TOP PLATE C TO C DIA. (B) 5.50 BOTTOM PLATE HOLE/STUD QTY 1 BOTTOM PLATE DIA. (C) 10.28 BOTTOM PLATE C TO C DIA. (D) N/A BOTTOM PART # BS14552 BUMPER YES BRACKET N/A MIN. HEIGHT 7.30

HK0004497

1059610

ROOF BOW TAPE, 1/8"X5/8", 2-SIDED, TOTAL LENGTH 100' PER ROLL

HK0004313

HTU114114X24

1 1/4"X1 1/4" X .100 HSS X 24', SQUARE TUBE, STEEL

HK0003259

D-28596-32

HUBS, WHEEL HUB, TRAILER, AIR DISC BRAKE, 10 STUD X 11.25" BC, TAPPER SPINDLE BENDIX ADB22X-LT AIR DISC BRAKE APPLICATION TYPE :- BOTH STEEL AND ALUMINUM WHEELS MATERIAL :- DUCTILE IRON CAN BE USED AS A SUBSTITUTE OF D-28596-31 ABS YES ABS TEETH 100 BETWEEN THE RACES 3.34 IN DRUM/ROTOR BOLT CIRCLE (10) ON 9.82 IN DRUM/ROTOR PILOT 8.66 IN HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 5.50 IN INNER BREAING HM218248 INNER RACE HM218210 INNER SET SET414 OE REF NUMBER C-34582-2 OUTER BEARING HM212049 OUTER RACE HM212011 OUTER SET SET413 OVERALL HEIGHT 7.82 IN WHEEL SEAL WS880025 WHEEL STUD 13-1572

HK0000490

W16100-BK

100 FT PRIMARY WIRE BLACK 16 GAUGE

HK0002640

AB1DK25B-8710

AIR BAG ROLLING LOBE APPLICATIONS HENDRICKSON TRAILER TYPE ROLLING LOBE LOAD (LBS) @80 PSI 6760 LOAD (LBS) @100 PSI 8450 NATURAL FREQ. (CPM) 75 DESIGN HEIGHT (IN) 10.50 BOTTOM PLATE TYPE PLASTIC TOP PLATE HOLE/STUD QTY 2 TOP PLATE DIA. (A) 10.20 TOP PLATE C TO C DIA. (B) 5.50 BOTTOM PLATE HOLE/STUD QTY 4 BOTTOM PLATE DIA. (C) 10.20 BOTTOM PLATE C TO C DIA. (D) 5.66" BOTTOM PART # BS17377 BUMPER YES BRACKET N/A MIN. HEIGHT 7.10 MAX. HEIGHT 19.00 MAX. DIA. 13.70

HK0000493

W16100-BR

100 FT PRIMARY WIRE BROWN 16 GAUGE

HK0001110

VS-32074-100

CONTROLLER ASSEMBLY TIREMAXX PRO 100 PSI
