PARTS CATALOG

HK0003795

S-21028-1

FRAME BRACKET ASSEMBLY HENDRICKSON, INTRAAX, AA MODELS, QUICK-ALIGN ROADSIDE, FOR CURBSIDE USE S-21028-2,, 13.5", , 14.0" AND 15.0" RIDE HEIGHTS TOP TO ALIGN HOLE: 8.0"

HK0003086

S-22889-3

ABS SENSOR,STRAIGHT HEAD, 39.0IN(1M )LENGTH, KE PLUG, CS WIRE

HK0003927

S-21454-1

FRAME BRACKET ASSEMBLY, WELD ON ,WINGLESS, ROAD SIDE, HENDRICKSON, 21-003

HK0003969

S-20271-1

FRAME HANGER LH HENDRICKSON/TURNER, FLEET STANDARD, HT300U-17-001, 001, 024

HK0003961

S-23166-1

FRAME BRACKET ASSEMBLY, WELD ON ,ROAD SIDE, EXTENDED REBOUND TRAVEL, RIDE 6.5", 8" PIVOT HEIGHT

HK0003922

S-20197-1

FRAME BRACKET LH HEN/TURNER, WINGLESS, WELD-ON HTDOLLY14-003, 005; HC190T-14-003; HC230-14-005, ROADSIDE, FOR CURBSIDE USE S-20197-1 TOP TO ALIGN HOLE: 11.0"

HK0003895

S-22828-2

WELD-ON FRAME BRACKET, CURBSIDE, FOR HT HT250US, HT HT300US, 18" , 19" RIDE HEIGHT

HK0003393

S-28062-1

LINE ACTUATOR, HENDRICKSON, REAR, 42" BOX, WITH STRAIGHT-FITTING, MAX INFLATION TO 120 PSI, CAST IRON TYPE BUILT BEFORE 02-2015 ( WITH STRAIGHT TRAIL FOR COUPLING)

HK0003903

S-20065-1

FRAME BRACKET ASSEMBLY, HT TOP MOUNT; HT190-16-001;002;003;005;009; HT190-17-001;019;503;520; HTDOLLY14-003;005, HC190T-14-003, HC230-14-005, ROADSIDE, FOR CURBSIDE USE S-20065-2 TOP TO ALIGN HOLE 10"

HK0003085

S-22889-2

ABS SENSOR,STRAIGHT, 78.7 IN, HALDEX, 2 PIN

HK0003917

S-22137-1

FRAME BASE ASSEMBLY, BOLT ON, WINGLESS, ROAD SIDE

HK0003959

S-23848-1

FRAME BRACKET ASSEMBLY, WELD ON, WITH SHOCK MOUNT, RIDE HEIGHT 3.5", 4", PIVOT HEIGHT 4.5"

HK0003971

S-24183-1

FRAME BRACKET ASSEMBLY, ROAD SIDE, WELD ON ,HT300U MODEL, BB9-022

HK0003933

S-22281-2

FRAME BRACKET ASSEMBLY, CURB SIDE , BOLT ON, WINGLESS, HENDRICKSON

HK0003911

S-23461-1

FRAME BRACKET ASSEMBLY, WINGLESS WELD-ON FRAME BRACKET, QUIK-ALIGN, ROADSIDE, FOR HT SERIES

HK0003897

S-22826-2

FRAME BRACKET ASSEMBLY, HT250US 5.5" STD; 6.5" STD; 7.5" TILT, HT350US 5.5" 6.5" CURBSIDE; FOR ROADSIDE USE S-22826-2, WINGLESS, WELD-ON, TOP TO ALIGN HOLE 8",

HK0003805

S-21083-1

HANGER LH HENDRICKSON/TURNER, AA230, AA250, AAT 23K, 25K, 30K QUICK-ALIGN, WINGED, WELD-ON, STANDARD TOP PLATE RIDE HEIGHTS: 18.0IN, 19.0IN, PIVOT HEIGHT: 12.0IN ROADSIDE, FOR CURBSIDE USE S-21083-1

HK0003957

S-20326-1

FRAME BRACKET ASSEMBLY LEFT, LH BOLT-ON UNDERSLUNG HT250U-6.5-007

HK0003889

S-21165-1

FRAME BRACKET ASSEMBLY, LH, ROADSIDE TOP TO ALIGN HOLE: 10" HT-DOLLY, HC, HT; AND TA, QUICK-ALIGN, FOR CURBSIDE USE S-21165-2

HK0003965

S-22829-1

FRAME HANGER LH HENDRICKSON/TURNER, HT250US ROADSIDE, FOR CURBSIDE USE MHT915 PIVOT HOLE TO TOP PLATE: 14IN, OVERALL HEIGHT: 17.5IN
