PARTS CATALOG

HK0003684

VS-29566-4

HUB CAP KIT WITH HARDWARE, TIREMAAX EC AND CP SERIES INFLATION SYSTEMS, HP AXLE, APPLICATIONS:- GREASE

HK0003663

VS-22535

BALL VAVE 3 WAY, HENDRICKSON, 1/4IN NPT; MANUAL DUMP VALVE WITHOUT AUTO RESET

HK0003804

S-21906-2

SUSPENSION FFRAME BRACKET ASSEMBLY, STANDARD WINGLESS WELD-ON FRAME BRACKET, STEEL, CURBSIDE, FOR INTRAAX AAT 23K/25K/30K, RIDE HEIGHT 16", 17"

HK0003457

AKH-244B

HEIGHT CONTROL VALVE KIT, DRUM BRAKE, FOR INTRAAX AAT

HK0003800

S-23000-2

STANDARD WINGLESS WELD-ON FRAME BRACKET, STEEL, CURBSIDE, FOR INTRAAXAAT 23K/25K/30K, 13.5, 14", 15" HEIGHT CONTROL RIDE HEIGHT, HENDRICKSON

HK0003799

S-23000-1

STANDARD WINGLESS WELD-ON FRAME BRACKET, STEEL, ROADSIDE, FOR INTRAAXAAT 23K/25K/30K, 13.5, 14", 15" HEIGHT CONTROL RIDE HEIGHT, HENDRICKSON

HK0003755

S-21477-8

STOP BAR MANUAL, 1-5/8" PIN FOR 48" BOX,

HK0003954

S-21927-2

FRAME BRACKET ASSEMBLY, WELD ON, WINGLESS CURBSIDE, HT250U, HENDRICKSON

HK0003832

S-36566-3R

FRAME BRACKET LH HENDRICKSON, CURBSIDE, FOR ROADSIDE USE S-36566-3L INTRAAX AAT 23K/25K/30K, 16", 17" RIDE HEIGHTS 10" WINGED BOLT ON TOP TO ALIGN HOLE: 10", BOLT SIZE: 1/2"

HK0003691

S-28146-2

2.5IN TMAX SPINDLE PLUG HEAD, PLUG DRIVER, 2.5 IN, FOR TIREMAAX

HK0003765

S-36186-9

SURELOK, RIDE HEIGHT LOCK ASSEMBLY, FOR 42" BOX, FOR VANTRAAX HKANT 23K/40K/46K/69K23 AND HKA180, HKAT 46K

HK0003940

S-24228-2

FRAME BRACKET ASSEMBLY, BOLT ON , WINGLESS, CURBSIDE, HENDRICKSON

HK0003168

S-38163-1

HUBS, WHEEL HUB, HENDRICKSON HUB ASSEMBLY WHEEL MATERIAL STEEL TAPPER SPINDLE TRAILER HUB, 12.25" BRAKE, HM518410 INNER CUP, HM518410 OUTER CUP BRAND: APPLICATION:- HLS, HVS,HXL3, HXL5 HENDRICKSON SHORT DESCRIPTION: WIDTH: 12.001 LENGTH: 12.001 WEIGHT: 46.3

HK0003634

VS-32087-4

TIREMAAX AXLE HOSE CONNEX ST, COMMON FOR GREAT DANE TRAILERS

HK0003673

VS-27449

SPINDLE PLUG END PLUG ASSY, TIREMAAX 2.75" , (FREEZE PLUG)

HK0003604

VS-32054-3

HUB CAP WINDOW REPLACEMENT KIT, TIREMAAX PRO, PRO, OIL, COMES WITH LENS; LENS PLATE AND SCREWS,

HK0003925

S-21123-1

FRAME BRACKET ASSEMBLY, HENDRICKSON, ROADSIDE, WELDON, 17-025

HK0003778

S-36187-8C

SURELOK, RH LOCK ASSY KIT:48"17" RIDE HEIGHT, 48IN BOX AIR SPRING ACTUATED SLKR-SLKN WITH 17.0IN RIDE HEIGHT,

HK0003909

S-22420-1

FRAME BRACKET ASSEMBLY, WELD ON, HT230T, TB15-025, WINGLESS, HENDRICKSON

HK0003550

VS-32057-1

HUB CAP,EXTENDED, OIL LUBE, FOR TIREMAAX, # OF BOLT HOLES:- 6, MATERIAL :- DIECAST ALUMINUM, AXLE:- TRAILER, SIDE FILL PLUG:- YES, BOLT HOLE CIRCLE DIA :- 6.750", FOR USE WITH CASTELLATED NUT SYSTEM

HK0003510

AKQD1008

ENCLOSURE ASSY WITH QUICK DRAW VALVE

HK0003501

VS-1314-C

DIAL-A-RIDE PACKAGE KIT, MANUAL LIFT CONTROLS, SUSPENSION RIDE HEIGHT CONTROL VALVE - REGULATING MANUAL

HK0003650

VS-32101

TIREMAXX AXLE VENT, FOR INTRAAX/VANTRAAX

HK0003097

S-35720-1
