PARTS CATALOG

HK0002226

10085

SAF-T-LOCK STEEL ROUND E-TRACK LOGISTIC BAR

HK0003240

10082497

HUBS, WHEEL HUB, TRAILER , DISC BRAKE TYPE,TAPPER SPINDLE 10 STUD, PRESET, ABS, BENDIX ADB22X-LT, APPLICATION TYPE :- STEEL WHEELS BEARING NUMBER INBOARD - 246 431 BEARING NUMBER OUTBOARD - 245 427 FLANGE OFFSET 0.79 IN HUB MOUNTING SYSTEM HP10 HUB RATING 11500 PG LEAD TIME 5 DAYS MATERIAL ALUMINUM WEIGHT 118.0 PG WHEEL STUD BOLT CIRCLE DIAMETER 11.25 IN WHEEL STUD STANDOUT 2.56 IN WHEEL STUD THREAD M22 X 1.5 MM MM

HK0001468

1000835898

ELECTRICAL CORD 100FT

HK0003195

10082438

HUBS, WHEEL HUB, DRUM BRAKES ALUM HUB PRESET TP ABS MATERIAL ALUMINUM AXLE POSITION TRAILER AXLE TP TRAILER - PARALLEL SPINDLE ASSEMBLY TYPE PRESET CASTING 10086449 BEARING SET (INBOARD) SET: 415 OR 432 BEARING SET (OUTBOARD) SET: 415 OR 432 COMPATIBLE BRAKE TYPE DRUM HUB MOUNTING SYSTEM HP10 WHEEL STUD STANDOUT (IN.) 3.81 WHEEL MATERIAL ALUMINUM WHEELS AND STEEL WHEELS FLANGE OFFSET (IN.) 1.42 BRAKE DRUM PILOT (IN.) 8.78 CAN USE AS A SUBSTITUDE FOR 10082436 OR 10082228

HK0003162

10082448

WHEEL HUB, ALUMINUM, PRESET, TN TRAILER -TAPERED SPINDLE MOUNTING HUB PILOTED - 8 STUDS ABS YES ABS CHARACTERISTIC STAMPED ABS RING WHEEL STUD BOLT CIRCLE DIAMETER 275 MM WHEEL STUD 102190 WHEEL STUD STANDOUT 3.80" HUB RATING 5,216 KG HUB CAP BOLT CIRCLE DIAMETER 5.500" DRUM PILOT DIAMETER 9.00" BEARING SET _-STAND PREMIUMCX ABS OFFSET 2.34" HUB OFFSET 0.34" CAN USE FOR 10082446 FOR BOTH STEEL AND ALUMINUM WHEEL

HK0001570

575.1085

WASHER FLUID RESERVOIR VOLVO

HK0003156

10082440

HUBS, WHEEL HUB, ALUMINUM, TRAILER, TAPERED SPINDLE, PRESET R DRIVE HUB, WITH LONG WHEEL STUDS HUB MOUNTING SYSTEM HP10 WHEEL STUD STANDOUT (IN.) 2.94 WHEEL MATERIAL STEEL WHEELS FLANGE OFFSET (IN.) 0.34 BRAKE DRUM PILOT (IN.) 8.78 PILOT DIAMETER 8.78 IN INNER BEARING CONE NUMBER 429 STUD LENGTH 3.96 IN

HK0003241

10083396

HUBS, WHEEL HUB, TRAILER, AIR DISC BRAKE , TAPPER SPINDLE,, 10 STUD, APPLICATION TYPE :- BOTH STEEL AND ALUMINUM WHEELS, LONG STUD FLANGE OFFSET 1-51/64 IN (2.03 CM) HUB RATING (LB) 11500 LBS (5228 KG) INNER BEARING CUP NUMBER 431 OUTER BEARING CUP NUMBER 427 STUD LENGTH 3-7/16 IN (8.74 CM) WHEEL STUD BOLT CIRCLE DIAMETER 11-1/4 IN (28.58 CM) WHEEL STUD THREAD SIZE M22 X 1.5 MM

HK0001488

VC-100

TIRE VALVE CORES

HK0003136

C10085

LANDING GEAR INPUT SPUR GEAR FOR JOST

HK0001082

1485-6-100

AIR LINE 3/8 DOT AIRBRAKE TUBE 3/8 BLK. 100 FT

HK0003161

10082442

HUBS, WHEEL HUB, TRAILER, ALUMINUM PRESET, LONG STUD AXLE -TAPERED SPINDLE BEARING SET (INBOARD) :-SET: 414 OR 431 BEARING SET (OUTBOARD) :-SET: 413 OR 427 COMPATIBLE BRAKE TYPE DRUM HUB MOUNTING SYSTEM HP10 WHEEL STUD STANDOUT (IN.) 3.80 WHEEL MATERIAL ALUMINUM WHEELS FLANGE OFFSET (IN.) 0.34 BRAKE DRUM PILOT (IN.) 8.78 ABS TONE RING INCLUDED YES CAN USE FOR BOTH STEEL AND ALUMINUM WHEEL ALTERNATIVE USE FOR 10082440

HK0003280

10083516

HUBS, WHEEL HUB, TRAILER, AIR DISC BRAKE, PARALLEL SPINDLE, 10 STUD X 11.25" BRAKE TYPE :- BENDIX ADB22X-LT APPLICATION TYPE :- BOTH STEEL AND ALUMINUM WHEELS Drum/rotor pilot 8.66 in Hubcap Holes 5/16-18 in Hubcap Mount (6) on 6.75 in Inner Breaing HM518445 Inner Race HM518410 Inner Set SET415 OE Ref Number S-28534-1 Outer Bearing HM518445 Outer Race HM518410 Outer Set SET415 Overall Height 8.89 in Wheel Mount (10) on 11.25 in Wheel Offset 1.79 in Wheel Seal WS880065 Wheel Stud 13-1572

HK0002649

10045885

WHEEL SEAL, FREIGHTLINER, INTERNATIONAL, KENWORTH, MERITOR, PETERBILT, VOLVO

HK0004516

1000841183

HUSKY 3/8 INCH REGULATOR
