PARTS CATALOG

HK0002640

AB1DK25B-8710

AIR BAG ROLLING LOBE APPLICATIONS HENDRICKSON TRAILER TYPE ROLLING LOBE LOAD (LBS) @80 PSI 6760 LOAD (LBS) @100 PSI 8450 NATURAL FREQ. (CPM) 75 DESIGN HEIGHT (IN) 10.50 BOTTOM PLATE TYPE PLASTIC TOP PLATE HOLE/STUD QTY 2 TOP PLATE DIA. (A) 10.20 TOP PLATE C TO C DIA. (B) 5.50 BOTTOM PLATE HOLE/STUD QTY 4 BOTTOM PLATE DIA. (C) 10.20 BOTTOM PLATE C TO C DIA. (D) 5.66" BOTTOM PART # BS17377 BUMPER YES BRACKET N/A MIN. HEIGHT 7.10 MAX. HEIGHT 19.00 MAX. DIA. 13.70

HK0002068

87141

NOSE BOX, 7 WAY, GREY, SOLID PIN

HK0000833

87910

DRILL BIT 3/8 SMALL (HD SUPER PREMIUM) "135-AG"
