PARTS CATALOG

HK0002071

SET414

BEARING, SKF BEARING SET HM218248/210 BORE DIA :-3.543" CUP ID :- 5.787" WIDTH :- 1.575"

HK0000445

SET415

BEARING SET, HM518445 / HM518410

HK0002739

SET428

BEARING

HK0001915

SET423

BEARING SET

HK0001914

SET424

BEARING SET

HK0001768

ABP/SBN-SET415

BEARING SET

HK0002740

SET429

BEARING, Consists of NP034946 / RBT1-0434PS Bearing and NP363298 / LBT1-0434PS Race for PreSet Hub

HK0001812

ABP/SBN-SET413

BEARING WHEEL

HK0001913

SET413

BEARING ,SKF BEARING SET HM212049/011

HK0002741

SET430

BEARING, Consists of NP840302 / RBT1-0431PS Bearing and NP053874 / LBT1-0431PS Race for PreSet Hub

HK0003260

S-35025-2

HUBS, WHEEL HUB, TRAILER ,AIR DISC BRAKE , 10 STUD X 11.25" BC, TAPPER SPINDLE, SUBSTITUTE FOR S-35025-1, S-35025-3, S-35025-4 HENDRICKSON MAXX22T AIR DISC BRAKE APPLICATION TYPE :- BOTH STEEL AND ALUMINUM WHEELS ( LONG STUD) MATERIAL :_ DUCTILE IRON ABS NO BETWEEN THE RACES 3.34 IN DRUM/ROTOR BOLT CIRCLE (10) ON 9.82 IN DRUM/ROTOR PILOT 8.66 IN HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 5.50 IN INNER BREAING HM218248 INNER RACE HM218210 INNER SET SET414 OUTER BEARING HM212049 OUTER RACE HM212011 OUTER SET SET413 OVERALL HEIGHT 7.22 IN WHEEL MOUNT (10) ON 11.25 IN WHEEL OFFSET .79 IN WHEEL SEAL WS880025 WHEEL STUD 13-1572

HK0003258

S-36701-2

HUBS, WHEEL HUB, TRAILER ,AIR DISC BRAKE, 10 STUD X 11.25" BC WABCO PAN19 AIR DISC BRAKE TYPE APPLICATION TYPE :- BOTH STEEL AND ALUMINUM WHEELS MATERIAL:- DUCTILE IRON IT CAN USE AS SUBSTIUTE OF S-36701-1 DRUM/ROTOR BOLT CIRCLE (10) ON 9.82 IN DRUM/ROTOR PILOT 8.66 IN HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 5.50 IN INNER BREAING HM218248 INNER RACE HM218210 INNER SET SET414 OE REF NUMBER S-33386-2 OUTER BEARING HM212049 OUTER RACE HM212011 OUTER SET SET413 OVERALL HEIGHT 7.22 IN WHEEL MOUNT (10) ON 11.25 IN WHEEL OFFSET .79 IN WHEEL SEAL WS880025 WHEEL STUD 13-1572

HK0003259

D-28596-32

HUBS, WHEEL HUB, TRAILER, AIR DISC BRAKE, 10 STUD X 11.25" BC, TAPPER SPINDLE BENDIX ADB22X-LT AIR DISC BRAKE APPLICATION TYPE :- BOTH STEEL AND ALUMINUM WHEELS MATERIAL :- DUCTILE IRON CAN BE USED AS A SUBSTITUTE OF D-28596-31 ABS YES ABS TEETH 100 BETWEEN THE RACES 3.34 IN DRUM/ROTOR BOLT CIRCLE (10) ON 9.82 IN DRUM/ROTOR PILOT 8.66 IN HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 5.50 IN INNER BREAING HM218248 INNER RACE HM218210 INNER SET SET414 OE REF NUMBER C-34582-2 OUTER BEARING HM212049 OUTER RACE HM212011 OUTER SET SET413 OVERALL HEIGHT 7.82 IN WHEEL SEAL WS880025 WHEEL STUD 13-1572

HK0003171

01025LT

HUBS, WHEEL HUB, TRAILER, HUB TN (TAPPER SPINDLE) 10 HOLE UNIMOUNT, RACES, LONG STUDS, TONE RING 16.5X7/202315T CAN USE S-35216-4 AND 20231--5T AS ALTERNATIVE 5/16-18 IN HUBCAP MOUNT (6) ON 5.50 IN INNER BREAING HM218248 INNER RACE HM218210 INNER SET SET414 OE REF NUMBER 20231-5T OUTER BEARING HM212049 OUTER RACE HM212011 OUTER SET SET413 OVERALL HEIGHT 7.22 IN

HK0003277

S-38161-4

HUBS, WHEEL HUB, TRAILER, AIR DISC BRAKE, TAPPER SPINDLE, 10 STUD X 11.25" MATERI L:- DURA LIGHT APPLICATION TYPE :- BOTH STEEL AND ALUMINUM WHEELS ( LONG STUD) BRAKE TYPE:- HENDRICKSON MAXX22T INNER BEARING SET :- SET414 OUTER BEARING SET :- SET413

HK0003273

S-33386-6

HUBS, WHEEL HUB, TRAILER AIR DISC BRAKE, TAPPER SPINDLE TYPE,10 STUD X 11.25" , APPLICATION TYPE:- BOTH STEEL AND ALUMINUM WHEELS HENDRICKSON MAXX22T, WABCO PAN19, PAN22, HALDEX DB22LT HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 5.50 IN INNER BREAING HM218248 INNER RACE HM218210 INNER SET SET414 OE REF NUMBER S-33386-2 OUTER BEARING HM212049 OUTER RACE HM212011 OUTER SET SET413 OVERALL HEIGHT 7.22 IN WEIGHT 56.900000 WHEEL MOUNT (10) ON 11.25 IN WHEEL OFFSET .79 IN WHEEL SEAL WS880025 WHEEL STUD 13-1572

HK0003253

S-34576-3

HUBS, WHEEL HUB, TRAILER, AIR DISC BRAKE , 10 STUD, WABCO PAN22 HALDEX DB22LT APPLICATION TYPE :- STEEL WHEELS DRUM/ROTOR PILOT 8.66 IN HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 5.50 IN INNER BREAING HM218248 INNER RACE HM218210 INNER SET SET414 OE REF NUMBER S-33386-1 OUTER BEARING HM212049 OUTER RACE HM212011 OUTER SET SET413 OVERALL HEIGHT 7.22 IN WHEEL MOUNT (10) ON 11.25 IN

HK0003252

S-34576-2

HUBS, WHEEL HUB, TRAILER , TAPPER SPINDLE, AIR DISC BRAKE , 10 STUD WABCO PAN22, HALSEX DB22LT APPLICATION TYPE :- BOTH ALUMINUM AND STEEL WHEELS DRUM/ROTOR PILOT 8.66 IN HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 5.50 IN INNER BREAING HM218248 INNER RACE HM218210 INNER SET SET414 OE REF NUMBER S-33386-2 OUTER BEARING HM212049 OUTER RACE HM212011 OUTER SET SET413 OVERALL HEIGHT 7.22 IN WEIGHT 56.900000 WHEEL MOUNT (10) ON 11.25 IN WHEEL OFFSET .79 IN WHEEL SEAL WS880025 WHEEL STUD 13-1572

HK0003251

S-34576-1

HUBS, DrWHEEL HUB, TRAILER, TAPPER SPINDLE, AIR DISC BRAKE , 10 STUD, WABCO PAN22, HALDEX DB22LT APPLICATION TYPE :-STEEL WHEELS ( SHORT STUD) ABS NO BETWEEN THE RACES 3.34 IN DRUM/ROTOR BOLT CIRCLE (10) ON 9.82 IN UM/ROTOR PILOT 8.66 IN HUBCAP HOLES 5/16-18 IN HUBCAP MOUNT (6) ON 5.50 IN INNER BREAING HM218248 INNER RACE HM218210 INNER SET SET414 OUTER BEARING HM212049 OUTER RACE HM212011 OUTER SET SET413 OVERALL HEIGHT 7.22 IN WHEEL SEAL WS880025 WHEEL STUD 13-1571
